300 / 500V Single Core Electrical Cable Wire With Solid Copper Conductor With Light PVC Sheath
Product introduction:
Place of Origin: China Mainland
Brand Name: Shenzhen Chentiantai Cable
Certification: CE, CB, CCC
Model Number : BVV
Minimum Order : 100 Unit
Price : On Request
No. Of Conductor: Single Core
Cable Shape: Round
Conductor: Flexible Conductor
Insulation: PVC Compound
Sheath: PVC Compound
Application
Exposed wiring in air or in raceway, wet or dry location and used for mobile electrical equipment
Product Specification:
Nominal cross sectional Area (mm²) |
Upper limit of average outer diameter (mm) |
Maximum DC resistance at 20 ℃ (Ω/km) |
Minimum insulation resistance at 70 ℃ (MΩ/km) |
Approximate carrying capacity (A) |
Reference weight (Kg/km) |
1.5 | 3.5 | 13.3 | 0.010 | 25.4 | 22 |
2.5 | 4.2 | 7.98 | 0.009 | 34.5 | 34 |
4.0 | 4.8 | 4.95 | 0.007 | 44.5 | 51 |
6.0 | 6.3 | 3.30 | 0.006 | 58.3 | 75 |
10 | 7.6 | 1.91 | 0.0056 | 79.5 | 131 |
16 | 8.8 | 1.21 | 0.0046 | 111.0 | 186 |
25 | 11.0 | 0.780 | 0.0044 | 146 | 285 |
35 | 12.5 | 0.554 | 0.0038 | 180 | 392 |
50 | 14.5 | 0.386 | 0.0037 | 225 | 544 |
70 | 17.0 | 0.272 | 0.0032 | 280 | 755 |
* The ampacity of cable will be directly affected by the lay-out methods and the ambient temperature.
Features:
Permissible operating temperature at conductor | +70℃ | |
Short circuit temperature (duration max. 5 s) | 160℃ | |
Minimum installation temperature | Should not be lower than 0 ℃ | |
Max. Conductor permissible tensile stress | 50 N/mm ² | |
Minimum bending radius | 15 × cable Ø |
Advantage:
It has the advantages of acid and alkali resistance, oil resistance, moisture-proof, mildew resistance, etc
Other Information:
Packaging Details: Coil in foil
Delivery Time: 15 working days
Payment Terms : L/C, T/T
