450 / 750 V Single Core PVC Insulation With Flexible Copper Conductor Cable Without External Sheath
Product introduction:
Place of Origin: China Mainland
Brand Name: Shenzhen Chentiantai Cable
Certification: CE, CB, CCC
Model Number : BVR
Minimum Order : 100 Unit
Price : On Request
No. Of Conductor: Single Core
Cable Shape: Round
Conductor: Flexible Conductor
Insulation: PVC Compound
Sheath: None
Application
Exposed wiring in air or in raceway, wet or dry location and used for mobile electrical equipment
Product Specification:
Nominal cross sectional Area (mm²) |
No. Of Strands |
Max. outer diameter (mm) |
Maximum DC resistance at 20 ℃ (Ω/km) |
Minimum insulation resistance at 70 ℃ (MΩ/km) |
Approximate carrying capacity (A) |
Reference weight (Kg/km) |
2.5 | 19 | 4.1 | 7.41 | 0.011 | 34 | 34 |
4.0 | 19 | 4.8 | 4.61 | 0.009 | 44.5 | 50 |
6.0 | 19 | 5.3 | 3.08 | 0.0084 | 58 | 72 |
10 | 49 | 6.8 | 1.83 | 0.0072 | 79.5 | 127 |
16 | 49 | 8.1 | 1.15 | 0.0062 | 111 | 184 |
25 | 98 | 10.2 | 0.727 | 0.0058 | 146 | 304 |
35 | 133 | 11.7 | 0.524 | 0.0052 | 180 | 399 |
50 | 133 | 13.9 | 0.387 | 0.0051 | 228 | 548 |
70 | 189 | 16.0 | 0.268 | 0.0045 | 281 | 739 |
* The ampacity of cable will be directly affected by the lay-out methods and the ambient temperature.
Features:
Permissible operating temperature at conductor | +70℃ | |
Short circuit temperature (duration max. 5 s) | 160℃ | |
Minimum installation temperature | Should not be lower than 0 ℃ | |
Max. Conductor permissible tensile stress | 50 N/mm ² | |
Minimum bending radius |
D≤25mm 4D D>25mm 6D |
Advantage:
It has the advantages of acid and alkali resistance, oil resistance, moisture-proof, mildew resistance, etc
Other Information:
Packaging Details: Coil in foil
Delivery Time: 15 working days
Payment Terms : L/C, T/T
