Flat Flexible Copper Conductor Multi Core Electrical Cable 300 / 500V H05VV-F

Negotiable
MOQ
Negotiable
Price
Flat Flexible Copper Conductor Multi Core Electrical Cable 300 / 500V H05VV-F
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Copper Building Wire
No. Of Conductor: Two Cores
Size: 0.75 Mm
Cable Shape: Round
Insulation: PVC Compound With Mica Layer
Type: Coppe Electrical Cable
High Light:

0.75mm Multi Core Electrical Cable

,

Copper Conductor Multi Core Electrical Cable

,

IEC Coppe Electrical Cable

Basic Infomation
Place of Origin: Shenzhen,China (Mainland)
Brand Name: CTT cable
Certification: IEC, CE, RoHS,ISO
Model Number: RVVB 2 0.75
Payment & Shipping Terms
Packaging Details: Coil in foil (100 m)
Delivery Time: 7/ 15 working days
Payment Terms: L/C, T/T
Product Description

300 / 500V H05VV-F Flat Multi Core Flexible Copper Conductor Electrical Cable


Product introduction:

Place of Origin: China Mainland

Brand Name: Shenzhen Chentiantai Cable

Certification: CE, CB, CCC

Model Number : RVVB

Minimum Order : 100 Unit

Price : On Request

No. Of Conductor: Two Cores

Outer Shape: Flat

Conductor: Flexible Conductor

Insulation: PVC Compound

Sheath: PVC Compound


Application:

Exposed wiring in air or in raceway, wet or dry location and used for mobile electrical equipment


Product Specification:

Nominal cross sectional

Area

(mm²)

Upper limit of average outer diameter

(mm)

Maximum DC resistance at 20 ℃

(Ω/km)

Approximate carrying capacity

(A)

Reference weight

(Kg/km)

2x0.75 4.2*8.4 26.0 13.0 45.0
2x1.0 4.3*8.6 19.5 20.0 65.0
2x1.5 4.8*9.6 13.3 25.4 65.0
2x2.5 5.4*10.8 7.98 34.5 88.0
2x4 6.2*12.4 4.95 44.5 137.0
2x6 7.0*14.0 3.30 53.0 188.0

* The ampacity of cable will be directly affected by the lay-out methods and the ambient temperature.



Features:

Permissible operating temperature at conductor +70℃
Short circuit temperature (duration max. 5 s) 160℃
Minimum installation temperature Should not be lower than 0 ℃
Max. Conductor permissible tensile stress 50 N/mm ²
Minimum bending radius 15 × cable Ø


Advantage:

It has the advantages of acid and alkali resistance, oil resistance, moisture-proof, mildew resistance, etc





Other Information:

Packaging Details: Coil in foil

Delivery Time: 15 working days

Payment Terms : L/C, T/T
